Bafang LCD Display DP C15.U 1.1
Technical specifications
Type of display: LCD
Display: Matrix Display
Rated Voltage(DCV): 36/43/48
Support Modes: 0-5
Operating Temperature: -20 - 45℃
Weight: ~ 45g
Installation parameter
Bus system: UART
Dimensions 65 x 46 x 44 mm
Handlebar diameter: Ø 22.2 mm
Cable Length: ~ 470 mm
Connector Type: Jullet 5 PIN, female, green
Display indications
Current speed (km/h)
Maximum speed (km/h)
Average speed (km/h)
Duration of single trip
Distance of single trip
Total Distance
Reset single trip Duration
Reset single trip Distance
Capacity
Error code display
Walk Boost
Backlight
Tests & Certification
IP code: IP X5
certifications: CE / EN 15194 / REACH / ROHS
Dimensions:
Dimension A 65 mmDimension B 46 mmDimension C 44 mmDimension D Ø 22.2 mmDimension E 28 mmDimension F 16 mmDimension G 1.2''
Thumb throttle for ebike or pedelec female
Control the power of your motor from the comfort of your handlebars!
The thumb throttle is simply connected / connected to the wiring harness of your bike thanks to the 3 PIN female Jullet Higo, Nexmo connector.
Details:
Connectors: 3 PIN female Jullet, Higo, Nexmo, yellow.
Cable length: ~ 47 cm
Mounting: handlebar with 22.2 mm diameter, left and right handlebar side possible
compatible with Bafang motors
Original thumb throttle from Urban Drivestyle Berlin!
Special Straight Handlebar CC4S small flat and sporty
All CCxS are made out of Hi-Ten Steel and have a chrome plating.
Diameter: 22,2 mm (~0,87 inches) with a clamp diameter (for the stem) of 25,4mm (~1 inch).
No Rise, just flat and straight
For your boardtracker or Fixie Bike Width: 51,5 cm (~20,27 inches) , Barbore: 2.54 cm (~1 inch)
