Tire Liner for tires 20-29 inch
Easy installing between Tube and Tire.
Tire Liners are reusable and are made of PUR POP material.
They will provide a lifetime of protection from puncture caused by sharp objects.
One Piece
Width: 80 mm (~3,15 inches)
Thick: 1,1 mm (~0,043 inches)
Length: 2350 mm (~ 92,52 inches)
~ 255 g ( ~ 0,56 lbs)
Assembling instruction:
Remove the wheel and let the air out of the tube.
Remove tire and tube from rim.
Make sure that the inside of the tire is free from sharp bodies.
Place a puncture protection insert in the tire. The ends can overlap by 7 - 10 cm.
Please shorten to the required length.
Inflate the tube a little (0,5 BAR / 7 PSI) and place back in the tire.
The puncture protection insert is fixed by the tube.
Mount the tire and tube on the rim and inflate to the desired tire pressure.
Tire Liner for tires 20-29 inch
Easy installing between Tube and Tire.
Tire Liners are reusable and are made of PUR POP material.
They will provide a lifetime of protection from puncture caused by sharp objects.
One Piece
Width: 100 mm (~3,94 inches)
Thick: 1,3 mm (~0,051 inches)
Length: 2350 mm (~ 92,52 inches)
~ 400 g (~ 0,88 lbs)
Assembling instruction:
Remove the wheel and let the air out of the tube.
Remove tire and tube from rim.
Make sure that the inside of the tire is free from sharp bodies.
Place a puncture protection insert in the tire. The ends can overlap by 7 - 10 cm.
Please shorten to the required length.
Inflate the tube a little (0,5 BAR / 7 PSI) and place back in the tire.
The puncture protection insert is fixed by the tube.
Mount the tire and tube on the rim and inflate to the desired tire pressure.
Fat Bike Plastic Fender Set 26 x4.0 - 4.8 inch. Fender Stays 124 mm (~4,88 inches) width
124 mm (~4,88 inches) wide, 26 inch., black matte
Can also be fitted on 24 x 4 1/4 Tires
complete plastic fender set for Fat Bikes or similar bike types
Width: 124 mm (~4,88 inches)
Hight: 35 mm (~1,38 inches)
Diameter inside: ~ 770 mm (~30,31 inches)
Diameter outside: ~ 810 mm (~31,89 inches)
Rear length in circumference: ~1190 mm (~46,85 inches)
Front length in circumference: ~ 700 mm (~27,56 inches)
Polycarbunate plastic black matte
Weight: ~ 1200 g. (~2,65 pounds)
Fat Bike Plastic Fender Set 26 x4.0 - 4.8 inch. Fender Stays 124 mm (~4,88 inches) width
124 mm (~4,88 inches) wide, 26 inch., black
Can also be fitted on 24 x 4 1/4 Tires
complete plastic fender set for Fat Bikes or similar bike types
Width: 124 mm (~4,88 inches)
Hight: 35 mm (~1,38 inches)
Diameter inside: ~ 770 mm (~30,31 inches)
Diameter outside: ~ 810 mm (~31,89 inches)
Rear length in circumference: ~1190 mm (~46,85 inches)
Front length in circumference: ~ 700 mm (~27,56 inches)
Polycarbunate plastic black glossy
Weight: ~ 1200 g. (~2,65 pounds)
Street Hog III Extra Wide Tire 20 x 4 1/4
Diameter: 406
For custom and chopper bikes like the Schwinn New Stingray.
This tire fits on all 20" Classic Cycle rims wider than 50 mm (~1,97 inches) ! But please check frame/fork for clearance!
On a 80 mm (~3,15 inches) rim the tire is about 93 mm (~3,66 inches) wide and it will 70 mm (~2,75 inches) protrude over the rim.
Depending on the rim width and the air pressure, the tire has a total diameter of approx. 60 cm.
30TPI
Weight: ~ 1,67 kg (~3,68 pounds)
External Diameter of Street Hog III 20 x 4 1/4 on 82 mm (~3,23 inches) rim is ~560 mm (~22,05 inches) - May vary because of pressure.
If you assemble the tire on wide rims not to put more pressure than 30 PSI. It could blast.
"E-Huntsman 20 x 4.0 inch tyre"
20" fatbike tyre specially developed for e-bikes!The E-Huntsman promises high riding comfort on the road as well as on loose off-road surfaces.The override technology guarantees increased puncture protection.For customs or chopper bikes like the Schwinn New Stingray, UNI MK, Super 73, Mate X, Mario and many more!This tyre fits CLASSIC CYCLE 20" rims from approx. 50 mm width! However, please note clearance in frame and/or fork!
Dimensions / Details:
ETRTO: 102 x 406
Max: 36 PSI / 2,5 Bar / 250 kPa
Over Ride E-Bike ready 50
Material: EndC - Endurance Compound
Mounted on an 82 rim, the tyre is approx. 10 cm / 3,93 inches wide and protrudes ~ 9 cm / 3,54 inches above the rim edge.
Total diameter: 60 cm / 23,62 inches
Offered is a tyre without rim.
Weight: ~ 2250 g / ~ 4,96 lbs.
204 Fat Bike Plastic Fender Set 20 x 4.0 - 4.8 inch. Fender Stays 124 mm (~4,88 inches) width
Mudguards with four stainless steel struts and mounting hardware for Fat Bikes 20 x 4.0 - 4.8 or similar.
Due to the variably adjustable struts, the mounting points on the frame can be flexibly selected.
The fenders are therefore also suitable for many common 20-inch Fat E-bikes.
124 mm (~4,88 inches) wide, 20 inch., black matte
complete plastic fender set for Fat Bikes or similar bike types
Width: 124 mm (~4,88 inches)
Hight: 35 mm (~1,38 inches)
Diameter inside: ~ 550 mm (~21,65 inches)
Diameter outside: ~ 610 mm (~24 inches)
Rear length in circumference: ~ 960 mm (~37,8 inches)
Front length in circumference: ~ 620 mm (~24,4 inches)
Polycarbunate plastic black matte
Weight: ~ 1080 g. (~2,65 pounds)
The Tannus Armour is an effective 3-in-1 puncture protection system!
By mounting it between tire and tube, the tube is enclosed by 360 degrees right into the rim bed and thus offers protection for the treads, sides and rims.
Puncture Protection for:
Tire - 75-100 x 406 / 20" x 3.3 - 4.0
*Tube - 60 - 100 x 406 / 20 x 2.4 - 3.5
Rim - 50 - 102 x 406
The all-round protection against punctures, cuts and pinching.
up to 15 mm at the tread, 3-5 mm at the sides and 2 mm in the rim area
free tire and tread selection
very light and reusable
support for the entire tire: even at lower air pressure, the Armour works against deformation by lateral forces, allowing greater grip and better traction
reduces the risk of snake bites (e.g. by a strong impact)
patented Aither 1.1 technology: very lightweight high-tech polymer foam with millions of bubbles provides shock and vibration damping
With flattened tube you can continue riding at reduced speed for a short period on flat paths.
easy mounting
anti-pinch protection for tube mounting
universal sizes for several widths
If necessary, the lips of the Tannus Armour can easily be shortened to the desired length with scissors.
recyclable
weight: 350 g
scope of delivery: 1 piece
*Attention: The puncture protection insert requires a smaller tube size due to its space requirement in the tire. Here a tube size of 20 x 2.5 - 3.5 is recommended.
204 Kenda Krusade Extra Wide Tire 20 x 4
Diameter: 406
98 - 406
Ideal for the 20 inch fat e-bikes!
This tire fits on all 20" Classic Cycle rims wider than 67 mm (~2,64 inches) ! But please check frame/fork for clearance!
On a 82 mm (~3,22 inches) rim the tire is about 95 mm (~3,74 inches) wide and it will 79 mm (~3,11 inches) protrude over the rim.
Diameter over all on this rim: 580 mm (22,83 inches)
60 TPI
5-30 PSI / 0,4 -2.1 bar / 40 - 210 KPA
Weight: ~ 990 g (~ 2,18258 pounds)
If you assemble the tire on wide rims not to put more pressure than 30 PSI. It could blast.
This offer includes 1 piece only
Fat Bike Tire Classic Cycle Zig Zag 26 x 4.0 whitewall
97/102-559
72 TPI = Lightweight and strong!
max load = 155kg/pc
About 87 mm (~4,25 inches) wide on a 80 mm (~3,15 inches) rim.
About 107 mm (~4,21 inches) wide on a 100 mm (~3,94 inches) rim.
This tire fits on all 26" Classic Cycle rims from 60 to 120 mm (~2,36 to 4,72 inches) width! But please check frame/fork for clearance!
The pictures shows the new Zig Zag Tire assembled on a 132 mm (~5,2 inches) wide rim.
Diameter complete: 730 mm + / - 20 mm (~28,74 +/- 0,79 inches) concerning to pressure and rim diameter.
Weight: 1890 g (~4,17 pounds)
If you assemble the tire on extra wide rims not to put more pressure than 16 PSI. It could blast.
1 piece
Tube recommendation: For rim widths up to 102 mm (~4 inches): 26 x 4.0 tube. For wider rims: till 26 x 5.0 tube
Notice:
The white sidewall has a very slight bluish tinge.The bluish part is to prevent yellowing.
Aluminium Alloy Rim 20 inch., 82 mm (~3,23 inches) wide
ETRTO: 406
double wall 82
Wide:
82 mm (~3,23 inches)
inner size:
75 mm (~2,95 inches)
Holes:
36
colour:
black
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
~ 1040 g (~2,3 pounds)
Aluminium Alloy Rim 20 inch., 82 mm (~3,23 inches) wide with cut out
ETRTO: 406
double wall 82
Wide:
82 mm (~3,23 inches)
inner size:
75 mm (~2,95 inches)
Holes:
36 (offset from the middle 15,5 mm)
colour:
black
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
882 g (~1,95 pounds)
Tire Kenda Kraze 20 x 4 1/4
97-406
THE ultra fat custom tire with oldschool tread
The ultimate custom cruiser tire for maximum performance!
On 82 mm (~3,23 inches) rim as shown it is 98 mm (~ 3,86 inches) wide and 61 mm (~ 2,4 inches) high (above the rim).
This tire fits rims of widths 67 mm (~2,64 inces) to 102 mm (~4,02 inches) width!
If you assemble the tire on wide rims not to put more pressure than 30 PSI. It could blast.
But please check frame/fork for clearance!
Weight: 1430 g (~ 3,15 pounds)
30 TPI
The Tannus Armour is an effective 3-in-1 puncture protection system!
By mounting it between tire and tube, the tube is enclosed by 360 degrees right into the rim bed and thus offers protection for the treads, sides and rims.
Puncture Protection for:
Tire - 100 -120 x 406 / 20" x 4.0 - 4.8
*Tube - 90 - 120 x 406 / 20 x 3.0- 4.0
Rim - 65 - 140 x 406
The all-round protection against punctures, cuts and pinching.
up to 15 mm at the tread, 3-5 mm at the sides and 2 mm in the rim area
free tire and tread selection
very light and reusable
support for the entire tire: even at lower air pressure, the Armour works against deformation by lateral forces, allowing greater grip and better traction
reduces the risk of snake bites (e.g. by a strong impact)
patented Aither 1.1 technology: very lightweight high-tech polymer foam with millions of bubbles provides shock and vibration damping
With flattened tube you can continue riding at reduced speed for a short period on flat paths.
easy mounting
anti-pinch protection for tube mounting
universal sizes for several widths
If necessary, the lips of the Tannus Armour can easily be shortened to the desired length with scissors.
recyclable
weight: 360 g
scope of delivery: 1 piece
*Please note: The puncture protection insert requires a smaller tube size due to its space requirement in the tire. Here a tube size of 20 x 3.0 - 3.75 is recommended.
From our list the Kenda Kraze 20 x 4.0 won't fit. It is not bollooning enaugh.
Street Hog III Monster Tire 24 x 4 1/4 pure black
for custom and chopper bikes
Inflate to 30 P.S.I.
Overall diameter on a 100 mm (~3,94 inches) rim: ~ 655 mm (~25,79 inches)
Overall diameter on a 80 mm (~3,15 inches) rim: ~ 665 mm (~25,79 inches)
On a 100 mm (~3,94 inches) rim the tire is about 103 mm (~4,05 inches) wide.
On a 80 mm (~3,15 inches) rim the tire is about 93 mm (~3,63 inches) wide.
Overall diameter, depending on rim width and air pressure about: 66 cm (~25,98 inches) + / - 2 cm (~0,79 inches).
ETRTO:108 - 507
Weight: 1,95 kg ( ~4,30 pounds)
This tire fits on all 24" Classic Cycle rims wider than 50 mm till 132 mm rims. But please check frame/fork for clearance!
If you assemble the tire on wide rims not to put more pressure than 30 PSI. It could blast.
Street Hog III Whitewall Tire 24 x 4 1/4
for custom and chopper bikes
Inflate to 30 P.S.I.
Overall diameter on a 102 mm (~4,01 inches) rim: ~ 655 mm (~25,79 inches).
Overall diameter on a 82 mm (~3,23 inches) rim: ~ 665 mm (~25,79 inches).
On a 102 mm (~4,01 inches) rim the tire is about 103 mm (~4,05 inches) wide
On a 80 mm (~3,15 inches) rim the tire is about 93 mm (~3,66 inches) wide.
ETRTO:108 - 507
Weight: 1,95 kg (~4,30 inches)
This tire fits on all 24" Classic Cycle rims wider than 50 mm till 132 mm rims. But please check frame/fork for clearance!
If you assemble the tire on wide rims not to put more pressure than 30 PSI. It could blast.
Fender Set 26 inch. Fender Stays 123 mm width
123 mm (~4,84 inches) wide, 26 inch., matte black and extra long in the rear
complete fender set for cruisers or similar bike types
Width: 123 mm (~4,84 inches)
Hight: 30 mm (~1,18 inches)
Diameter inside: ~ 770 mm (~30,3 inches)
Diameter outside: ~ 810 mm (~31,89 inches)
Rear lenght in circumference: ~125 cm (~49,2 inches)
Front length in circumference: ~ 80 cm (~31,5 inches)
Steel powder coated flat black
Weight: ~ 2,6 kg (~5,73 pounds)
On chainside of the rear fender you will find a benting to give way to the chain.
204 E-Speedster Whitewall Extra Wide Tire 20 x 4
The Speedster was designed for rolling speed and minimal drag on hard pack or paved terrain. The honeycomb center tread provides virtually zero rolling resistance and unbelievable tread life. The honeycomb feature also gives you excellent traction in dry or wet conditions. Large diamond shaped side knobs provide the grip you need in corners, while the tread knobs get smaller towards the center for the ultimate speed and traction. And with its balloon-style structure, you’ll feel like you’re floating on air
102 - 406
26 TPI
Edurance Compound
E-Bike 50, ECE - R75
8-20 PSI (0.6 - 1,4 bar)
For custom and chopper bikes like the Schwinn New Stingray.
This tire fits on all 20" Classic Cycle rims wider than 50 mm (~1,97 inches) ! But please check frame/fork for clearance!
On a 82 mm (~3,,22 inches) rim the tire is about 105 mm (~3,66 inches) wide and it will 72 mm (~2,83 inches) protrude over the rim.
Total external diameter: ~590 mm (~23,22 inches) - May vary because of pressure.
Weight: ~ 1,4 kg (~2,6 pounds)
If you assemble the tire on wide rims not to put more pressure than 20 PSI. It could blast.
This offer includes 1 piece only
Fat Bike Tire Classic Cycle Zig Zag 26 x 4.0
97/102-559
72 TPI = Lightweight and strong!
max load = 155kg/pc
About 87 mm (~3,42 inches) wide on a 82 mm (~3,22 inches) rim.
About 105 mm (~4,13 inches) wide on a 102 mm (~4,02 inches) rim.
Diameter complete: 730 mm + / - 20 mm (~28,74 +/-0,79 inches) concerning to pressure and rim diameter.
This tire fits on all 26" Classic Cycle rims from 60 to 120 mm (~2,36 to 4,72 inches) width! But please check frame/fork for clearance!
The last two pictures show the Zig Zag mounted on a 132 mm (~5,2 inches) wide black rim from us.
Attention: In these two pictures the labeling of the tires differs from the actual tires!
Weight: 1620 g (~3,57 pounds)
If you assemble the tire on extra wide rims do not to put more pressure than 16 PSI. It could blast.
1 Piece
Tube recommendation: 26 x 4.0 tube
204 Vee Rubber E-Speedster Extra Wide Tire 20 x 4
The Speedster was designed for rolling speed and minimal drag on hard pack or paved terrain. The honeycomb center tread provides virtually zero rolling resistance and unbelievable tread life. The honeycomb feature also gives you excellent traction in dry or wet conditions. Large diamond shaped side knobs provide the grip you need in corners, while the tread knobs get smaller towards the center for the ultimate speed and traction. And with its balloon-style structure, you’ll feel like you’re floating on air
102 - 406
26 TPI
Edurance Compound
E-Bike 50, ECE - R75
8-20 PSI (0.6 - 1,4 bar)
For custom and chopper bikes like the Schwinn New Stingray.
This tire fits on all 20" Classic Cycle rims wider than 50 mm (~1,97 inches) ! But please check frame/fork for clearance!
On a 82 mm (~3,,22 inches) rim the tire is about 105 mm (~3,66 inches) wide and it will 72 mm (~2,83 inches) protrude over the rim.
Total external diameter: ~590 mm (~23,22 inches) - May vary because of pressure.
Weight: ~ 1,2 kg (~2,6 pounds)
If you assemble the tire on wide rims not to put more pressure than 20 PSI. It could blast.
This offer includes 1 piece only
Fat Bike Tire Classic Cycle Fleetwood 26 x 4.0
100-559
30 TPI = Sturdy and strong!
Intensive tread knob layout offers excellent traction and gripping power
Shoulder tread knobs connecting design enhances comering grip power and stability
About 87 mm (~3,42 inches) wide on a 80 mm (~3,15 inches) rim.
About 107 mm (~4,12 inches) wide on a 100 mm (~3,94 inches) rim.
This tire fits on all 26" Classic Cycle rims from 60 to 120 mm (~2,36 to 4,72 inches) width! But please check frame/fork for clearance!
The pictures shows the new Fleetwood Tire assembled on a 132 mm (~5,2 inches) wide rim.
Diameter complete: 730 mm + / - 20 mm (~28,74 +/-0,79 inches) concerning to pressure and rim diameter.
Weight: 1700 g (~3,75 pounds)
If you assemble the tire on extra wide rims not to put more pressure than 16 PSI. It could blast.
1 Piece
Tube recommendation: 26 x 4.0 tube
Aluminium Alloy Rim 26 inch., 82 mm (~3,23 inches) wide
ETRTO: 559
double wall 82
the ultimate ultra fat custom chopper wheel
wide:
82 mm (~3,23 inches)
Inner size:
75 mm (~2,95 inches)
holes:
36
colour:
black
Rim diameter for calculating the spoke length:
536 mm (~21,10 inches)
Weight:
1400 g (~3,09 pounds)
20 inch Fat Bike Fender Set Fender Stays 123 mm width
123 mm (~4,84 inches) wide, 20 inch., matte black
complete fender set for 20 inch fat bikes or similar bike types
Width: 123 mm (~4,84 inches)
Hight: 30 mm (~1,18 inches)
Diameter inside: ~ 480 mm (~18,9 inches)
Diameter outside: ~ 530 mm (~20,87 inches)
Rear lenght in circumference: ~890 mm (~35,04 inches)
Front length in circumference: ~ 590 mm (~23,23 inches)
Steel powder coated flat black
Weight: ~ 1,8 kg (~3,97 pounds)
On chainside of the rear fender you will find a benting to give way to the chain.
204 Fat Bike Plastic Fender Set 20 x 4.0 - 4.8 inch. Fender Stays 124 mm (~4,88 inches) width
Mudguards with four stainless steel struts and mounting hardware for Fat Bikes 20 x 4.0 - 4.8 or similar.
Due to the variably adjustable struts, the mounting points on the frame can be flexibly selected.
The fenders are therefore also suitable for many common 20-inch Fat E-bikes.
124 mm (~4,88 inches) wide, 20 inch., black glossy
complete plastic fender set for Fat Bikes or similar bike types
Width: 124 mm (~4,88 inches)
Hight: 35 mm (~1,38 inches)
Diameter inside: ~ 550 mm (~21,65 inches)
Diameter outside: ~ 610 mm (~24 inches)
Rear length in circumference: ~ 960 mm (~37,8 inches)
Front length in circumference: ~ 620 mm (~24,4 inches)
Polycarbunate plastic black glossy
Weight: ~ 1080 g. (~2,65 pounds)
Aluminium Alloy Rim 26 inch., 82 mm (~3,23 inches) wide
ETRTO: 559
double wall 82
the ultimate ultra fat custom chopper wheel
wide:
82 mm (~3,23 inches)
Inner size:
75 mm (~2,95 inches)
holes:
36
colour:
High polished
Rim diameter for calculating the spoke length:
536 mm (~21,10 inches)
Weight:
1365 g (~3 pounds)
Aluminium Alloy Rim 26 inch., 82 mm (~3,23 inches) ide
ETRTO: 559
double wall 82
the ultimate ultra fat custom chopper wheel
wide:
82 mm (~3,23 inches)
Inner size:
75 mm (~2,95 inches)
holes:
36
colour:
raw
Rim diameter for calculating the spoke length:
536 mm (~21,10 inches)
Weight:
1395 g (~3,07 pounds)
Fat Bike Cartrige B.B. Set for 100mm housing
silver
for 100 mm bottom bracket housing
total length (L1): 159,50 mm (~6,28 inches)
L2: 25,5 mm (~1 inch)
430 gr.
BSA, JIS
sealed bearings
Dacromet coated axle
compatible with Shimano tools
204 Bike Tire Classic Cycle Zig Zag 20 x 4.0 whitewall
97/102-406
27 TPI
New Over Ride
Endurance Compound
E-Bike Ready 50
ECE-R75
max load = 155kg/pc
About 87 - 105 mm (~3,42 - 4,13 inches) wide on a 82 mm (~3,23 inches) rim.
About 110 mm (~4,33 inches) wide on a 102 mm (~4,01 inches) rim.
This tire fits on all 20" Classic Cycle rims from 60 to 102 mm (~2,36 to 4,01 inches) width! But please check frame/fork for clearance!
The pictures shows the new Zig Zag Tire assembled on a 102 mm (~4,01 inches) wide rim.
Diameter complete: 595 mm + / - 20 mm (~23,42 +/- 0,79 inches) concerning to pressure and rim diameter.
Weight: 1870 g (~ 4,12 lb)
If you assemble the tire on extra wide rims not to put more pressure than 16 PSI. It could blast.
1 piece
Tube recommendation: For rim widths up to 102 mm (~4 inches): 26 x 4.0 tube. For wider rims: till 26 x 5.0 tube
Fat Bike Cartridge B.B. Set for 120mm housing
black
for 120 mm bottom bracket housing
total length (L1): 180 mm (~7,08 inches)
L2: 32 mm (~1,26 inch)
~ 400 gr.
BSA, JIS
sealed bearings
compatible with Shimano tools
Aluminium Alloy Rim 20 inch., 102 mm (~4,01 inches) wide
ETRTO: 406
double wall 102
wide:
102 mm (~4,01 inches)
Inner size:
95 mm (~3,74 inches)
holes:
36
colour:
Black matte
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
1100 g (~2,42 pounds)
Aluminium Alloy Rim 24 inch., 102 mm (~4,01 inches) wide
ETRTO: 507
double wall 102
the ultimate ultra fat custom chopper wheel
102 mm wide (~4,01 inches), inner size: 95 mm (~3,74 inches), 36 holes
colour: black
Rim diameter for calculating the spoke length: 489 mm (~19,25 inches)
Weight: 1365 g (~3 pounds)
Aluminium Alloy Rim 24 inch., 82 mm (~3,23 inches) wide
ETRTO: 507
double wall
the ultimate ultra fat custom chopper wheel
82 mm (~3,23 inches) wide, inner size: 75 mm (~2,95 inches), 36 holes
Wide:
82 mm (~3,23 inches)
inner size:
75 mm (~2,95 inches)
Holes:
36
colour:
black
Rim diameter for calculating the spoke length:
485 mm (~19,09 inches)
Weight:
1285 g (~2,83 pounds)
Fat Bike Tire Classic Cycle Fleetwood 24 x 4.0
100-507
60 TPI = Lightwight and strong!
Intensive tread knob layout offers excellent traction and gripping power
Shoulder tread knobs connecting design enhances comering grip power and stability
About 87 mm (~3,42 inches) wide on a 80 mm (~3,15 inches) rim.
About 107 mm (~4,12 inches) wide on a 100 mm (~3,94 inches) rim.
This tire fits on all 24" Classic Cycle rims from 60 to 120 mm (~2,36 to 4,72 inches) width! But please check frame/fork for clearance!
The pictures shows the new Fleetwood Tire assembled on a 100 mm wide rim.
Diameter complete: 650 mm + / - 20 mm (~25 +/-0,79 inches) concerning to pressure and rim diameter.
Weight: 1100 g (~2,42 pounds)
If you assemble the tire on extra wide rims not to put more pressure than 16 PSI. It could blast.
1 Piece
Tube recommendation: 24 x 4.0 or 24 x 4 1/4
Extra wide Front Hub for 100 mm (~3,94 inches) rims and extra wide forks for Disc Brakes
Fog Black matte
36 spoke holes
215 mm (~8,46 inches) axle
mounting size: 150 mm (~5,90 inches)
spacing between flanges: 91,7 mm (~3,61 inches)
PCD: 57,5 mm (~2,26 inches)
Weight: 398 gr. (~0,88 pounds)
204 Bike Tire Classic Cycle Zig Zag 20 x 4.0
97/102-406
27 TPI
New Over Ride
Endurance Compound
E-Bike Ready 50
ECE-R75
max load = 155kg/pc
About 87 - 105 mm (~3,42 - 4,13 inches) wide on a 82 mm (~3,22 inches) rim.
About 110 mm (~4,33 inches) wide on a 102 mm (~4,01 inches) rim.
This tire fits on all 20" Classic Cycle rims from 60 to 102 mm (~2,36 to 4,01 inches) width! But please check frame/fork for clearance!
The pictures shows the new Zig Zag Tire assembled on a 102 mm (~4,01 inches) wide rim.
Diameter complete: 595 mm + / - 20 mm (~23,42 +/- 0,79 inches) concerning to pressure and rim diameter.
Weight: 1810 g (~ 4 lb)
If you assemble the tire on extra wide rims not to put more pressure than 16 PSI. It could blast.
1 piece
Tube recommendation: For rim widths up to 102 mm (~4 inches): 26 x 4.0 tube. For wider rims: till 26 x 5.0 tube
Aluminium Alloy Rim 26 inch., 102 mm (~4,01 inches) wide
ETRTO: 559
double wall 102
the ultimate ultra fat custom chopper wheel
wide:
102 mm (~4,01 inches)
Inner size:
95 mm (~3,74 inches)
holes:
36
colour:
black matte
Rim diameter for calculating the spoke length:
536 mm (~21,10 inches)
Weight:
1490 g (~3,28 pounds)
Foot Rests
chrome-plated, 1 pair
can be also used as passenger foot rests
to be fixed on the frame (chain stay) or front fork of the bike
the real lowrider stuff!
Tube diameter min 24 mm (~0,94 inches) up to max. 30 mm (~1,18 inches)
E-Speedster Skinwall Extra Wide Tire 20 x 4 Woody
The Speedster was designed for rolling speed and minimal drag on hard pack or paved terrain. The honeycomb center tread provides virtually zero rolling resistance and unbelievable tread life. The honeycomb feature also gives you excellent traction in dry or wet conditions. Large diamond shaped side knobs provide the grip you need in corners, while the tread knobs get smaller towards the center for the ultimate speed and traction. And with its balloon-style structure, you’ll feel like you’re floating on air
102 - 406
26 TPI
Edurance Compound
E-Bike 50, ECE - R75
8-20 PSI (0.6 - 1,4 bar)
For custom and chopper bikes like the Schwinn New Stingray.
This tire fits on all 20" Classic Cycle rims wider than 50 mm (~1,97 inches) ! But please check frame/fork for clearance!
On a 82 mm (~3,,22 inches) rim the tire is about 105 mm (~3,66 inches) wide and it will 72 mm (~2,83 inches) protrude over the rim.
Total external diameter: ~590 mm (~23,22 inches) - May vary because of pressure.
Weight: ~ 1,4 kg (~2,6 pounds)
If you assemble the tire on wide rims not to put more pressure than 20 PSI. It could blast.
This offer includes 1 piece only
E-Mission Command Tire 20 x4 skinwall - woody
Diameter: 406
102 - 406
For custom and chopper bikes like the Schwinn New Stingray.
This tire fits on all 20" Classic Cycle rims wider than 50 mm (~1,97 inches) ! But please check frame/fork for clearance!
On a 82 mm (~3,,22 inches) rim the tire is about 97 mm (~ 3,82 inches) wide and it will 90 mm (~ 3,54 inches) protrude over the rim, diameter over all ~ 59 cm (~ 23,23 inches)
26TPI
Endurance Compound
E-Bike 50, ECE - R75
8-20 PSI (0.6 - 1.4 bar)
Weight: ~ 1,6 kg (~3,53 pounds)
If you assemble the tire on wide rims not to put more pressure than 30 PSI. It could blast.
This offer includes 1 tire.
204 Extra Wide Tire 20 x 4 brown
Diameter: 406
98 - 406
Ideal for the 20 inch fat e-bikes!
This tire fits on all 20" Classic Cycle rims wider than 67 mm (~2,64 inches) ! But please check frame/fork for clearance!
On a 82 mm (~3,22 inches) rim the tire is about 95 mm (~3,74 inches) wide and it will 79 mm (~3,11 inches) protrude over the rim.
Diameter over all on this rim: 580 mm (22,83 inches)
33 TPI
5-30 PSI / 0,4 -2.1 bar / 40 - 210 KPA
Weight: ~ 1260 g (~ 2,7 pounds)
If you assemble the tire on wide rims not to put more pressure than 30 PSI. It could blast.
This offer includes 1 piece only
Footrest black M10 thread for 20x4 E-bikes front / rearBlack
Do you love to race through the neighborhood and want to share this incredible riding experience with others? Then get some footrests now and take your friends on a bike tour! The footrests are also great for riding with kids who sit in front of the rider! In addition, they protect the shift arm and frame, should the bike fall over.
Handmade, solid and simple - The footrests with aluminum alloy are made for's riding with passengers and children and can be mounted quickly and easily, both front and rear. Due to the standardized M10 thread, they also fit other e-bikes and bikes.
Note: The footrests can be quickly and easily swapped between front and rear mount, if you increasingly ride with children and other passengers!
Features of the footrestsMaterial: alloyed aluminumThread: M10Colors: blackDimensions: L 9.8cm (7.8cm without threaded rod) x D 2cmWeight: 170g
Grub screw: Stainless steel 2A unhardened, can be tightened firmlyHandmadeServe as fall over protection for shifting unit and frameAlso fit other e-bikes and bikes with M10 thread1 pair
Put your feet up!
Aluminium Alloy Rim 26 inch., 102 mm (~4,01 inches) wide
ETRTO: 559
double wall 102
Wide:
102 mm (~4,01 inches)
inner size:
95 mm (~3,74 inches)
Holes:
36
colour:
high polished
Rim diameter for calculating the spoke length:
536 mm (~21,10 inches)
Weight:
1465 kg (~3,23 pounds)
€65.95*
This website uses cookies to ensure the best experience possible. More information...
