Sturmey Archer single-sided drum brake hubs (X-SD) Left

€79.95*

Currently no longer available, we are working on a new delivery

Product number: X-SD-L

Community Bilder

Product information "Sturmey Archer single-sided drum brake hubs (X-SD) Left"

Sturmey Archer single-sided drum brake hubs (X-SD) Left

single side mounted hub with 70mm drum brake - Specific side mounted, left side - Solid axle - Now with high polish hubshell

Specs for Solid Axle Model HSL881

  • Side: Left
  • Axle Type: HSL881 Solid Nutted
  • Axle Diameter / Type: 12 mm (0,47 inches)
  • Axle Length: 130 mm (~5,12 inches) (Excl. M19 Hex Bolt Head of 4 mm (~0,16 inches))
  • Axle Protrusion Length: 50mm (~1,97 inches)
  • Hub Shell Material: A356 Aluminum
  • Bearing Type: 6001-ZZ Sealed Cartridge x 2
  • Spoke Holes: 36
  • Pitch Circle Diameter: 89.8 mm (~3,53 inches)
  • Flange Width: 54 mm (~2,12 inches)
  • Spoke Compatibility: 13G or 14G
  • Weight: 790g (~1,74 pounds)
