UD special headset Ahead 1 1/8 inch black
durable and high quality 1 1/8" headset Ahead
for 1 1/8 inch shaft diameter
color: black
sealed roller bearings
Outer diameter bearing shell: 44 mm
Original headset for the UDX from Urban Drivestyle in Berlin
Not suitable for forks with threaded shaft!
Innovative and beautiful mini bell made of copper
very loud and long lasting sound (100dB)
body made of copper
diameter 30 mm / 1,18 inch
innovative assembly using 2 different fastening clamps 22.2 - 40 mm / 0,87 - 1,57 inch in diameter
weight 48 g / 0,11 pounds
incl. rubber inlay
colour black
For the assembly, only the upper screw is loosened with the help of an Allen key. Choose the appropriate fastening clamp and tighten everything again.
UD 204 Double Crown Suspension Fork Fatbike air-suspension, matt black
For 20 inch wheels with hubs of 135 mm installation width.
Adjustable preload.
1 1/8" shaft Ahead
Distance between axle centre and shock tower: ~ 330 mm
Distance between upper edge of upright pipes to axle mount: ~ 600 mm
Weight approx. 2.7 kg (with 220 mm shaft)
For disc brake disc (160 mm without adapter) PostMount
Scope of delivery: 1 piece
Steerer length
220 mm
Steerer diameter / stem width:
28,6 mm
Steerer diameter at cone seat:
30 mm
Installation hight:
420 mm
For Hub width:
135 mm
Travel:
~ 100 mm
Suspension:
Air in left stanchion
Damping:
Oil in right stanchion
Distance between steerer tubes at tyre height:
~ 115 mm
Original fork of the bikes from Urban Drivestyle Berlin!
Fat Bike Cartridge B.B. Set for 120mm housing
black
for 120 mm bottom bracket housing
total length (L1): 180 mm (~7,08 inches)
L2: 32 mm (~1,26 inch)
~ 400 gr.
BSA, JIS
sealed bearings
compatible with Shimano tools
Original UDX hardtail frame, raw
Build your own e-bike!
Made in Europe!
Details:
Paintwork: Without - raw
Steel
Hardtail
Possible rim and tyre sizes: 20" rims up to 102 mm / ~4 inches width, maximum tyre size 20 x 4.0
Bottom bracket: BSA 120 mm / 4,72 inches
Head tube diameter: 44 mm / 1,73 inches (measured inside)
Seatpost mount for 32 / 1,26 inches mm seatposts
Disc brake mount: yes
Coaster brake mount: no
derailleur: yes
Side stand plate: yes
Various mounting points on the rear triangle
Head tube length: 150 mm / 5,90 inches
Rear triangle width: 195 mm / 7,67 inches
Dimensions:
seat post mount -> head tube: ~ 565 mm / 22,24 inches
seat post mount -> bottom bracket: ~ 470 mm / 18,5 inches
seat tube: ~ 440 mm / 17,32 inches
Weight: ~ 5.8 kg / 12,78 lbs
various mounting points for e.g. batteries, controller....
Original frame from the UDX bike series by Urban Drivestyle Berlin!
€249.95*
€329.95*(24.25% saved)
