UD Controller motor DMHC 48V

Thumb throttle for ebike or pedelec female Control the power of your motor from the comfort of your handlebars! The thumb throttle is simply connected / connected to the wiring harness of your bike thanks to the 3 PIN female Jullet Higo, Nexmo connector. Details: Connectors: 3 PIN female Jullet, Higo, Nexmo, yellow. Cable length: ~ 33 cm Mounting: handlebar with 22.2 mm diameter, left and right handlebar side possible compatible with Bafang motors Original thumb throttle from Urban Drivestyle Berlin!

Bafang LCD 4" Display C961 Technical specifications Type of display: LCD Display: Matrix Display Rated Voltage(DCV): 36/43/48 Support Modes: 0-5 Operating Temperature: -20 - 45℃ Weight: ~ 60g Installation parameter Bus system: UART Dimensions 108 x 58 x 55 mm Handlebar diameter: Ø 22.2 mm Cable Length: ~ 200 mm Connector Type: Jullet 5 PIN, female, green Display indications Current speed (km/h) Maximum speed (km/h) Average speed (km/h) Duration of single trip Distance of single trip Total Distance Reset single trip Duration  Reset single trip Distance Capacity Error code display Walk Boost Backlight Time Tests & Certification IP code: IP 65 standard certifications: CE / EN 15194 / REACH / ROHS Original part from Urban Drivestyle Berlin

DC converter / voltage transformer with HIGO / Julet connections Input: 7 - 60 VDC Connector: 1x 2-pin HIGO / Julet female, red Output: 12V / 1000 mA Connector: 2x 2-pin HIGO / Julet male, red Total length incl. plug: ~ 30 cm Converter size: 43 x 21 x 10 mm General information: HIGO / Julet plugs are common on many e-bikes because they provide a firm and waterproof connection. There are different types, which differ in the number of pins and thus the area of use. A HIGO / Julet connector is generally quite firm because it is waterproof. It can be disconnected by pulling, NOT twisting. If twisted, the pins could be damaged. Please note the arrows on the outside - they help to align and fit the connectors. When the connections are properly plugged together, no coloured plastic should be visible.

Pre-assembled Bafang wiring harness 1T4 with 2PIN extension cable in cable protection hose. Technical data of Bafang wiring harness 1T4: Transmission of power and data between the controller and the brake sensors, thumb throttle and display. Compatible with Bafang hub motors Waterproof plugs / connectors Cable length: ~ 70 cm / 27,55 inches, incl. connector ~ 80 cm / 31,5 inches Connections: 1x male 3-PIN Julet connector yellow for throttle / thumb throttle. 1x male 5-PIN Jullet connector green for display 2x female 3-PIN Jullet connector yellow for shift / brake sensor 1x male 8-PIN Jullet connector black for controller Technical data of Extension cable for Ebike: Connector: 2-pin HIGO / Julet (1x male - 1x female) Water resistance: IP65 Cable length: 100 cm / 39,37 inches Plug connection: red Outer material: ABS plastic Technical data cable protection hose: Keeps cables tidy and protected! Diameter: ~ 20 mm Length: ~ 850 mm Fabric hose with practical Velcro fastener over the entire length General information: HIGO / Julet plugs are common on many e-bikes because they provide a firm and waterproof connection. There are different types, which differ in the number of pins and thus the area of use. A HIGO / Julet connector is generally quite firm because it is waterproof. It can be disconnected by pulling, NOT twisting. If twisted, the pins could be damaged. Please note the arrows on the outside - they help to align and fit the connectors. When the connections are properly plugged together, no coloured plastic should be visible.
