UD special headset Ahead 1 1/8 inch black
durable and high quality 1 1/8" headset Ahead
for 1 1/8 inch shaft diameter
color: black
sealed roller bearings
Outer diameter bearing shell: 44 mm
Original headset for the Moke or Swing from Urban Drivestyle in Berlin
Not suitable for forks with threaded shaft!
UD black crankset LASCO 155 mm, square, 52 teeth
black steel chainring with 52 teethblack aluminum crankspedal arm length 155 mm for pedals with 9/16 threadblack aluminium chain guardThe crankset is suitable for a square axle!With 2 pieces of axle - end bolts
Controller box, electronics box with seal for E-Bike Uni Moke and Swing
The controller box is made of robust plastic. In addition to attaching the controller to your e-bike, it also protects it.
Dimensions:
Outer dimension: ~ 21cm x 10.7cm x 3.4cm
Inner dimensions: ~ 15.5 cm x 8.2 cm x 2.5 cm
The box can be fitted to the frame of the Urban Dirvestyle Uni Moke and Swing bikes. It is screwed to the frame from below with the help of 4 screws. The cables are pulled upwards into the frame.
The scope of delivery includes the controller box and the matching self-adhesive seal.
Wiring harness 1T4
Technical data:
Transmission of power and data between e.g. the controller and the brake sensors, the thumb throttle and the display
Waterproof plugs / connectors
Cable length: ~ 56 cm / 22.05 inches, incl. connector ~ 66 cm / 26 inches
Connections:
3x female 3-PIN Jullet connector yellow
1x female 5-PIN Jullet connector green
1x male 2-PIN Jullet connector red
1x male 9-PIN Jullet connector black
General information:
HIGO / Julet plugs are common on many e-bikes because they provide a firm and waterproof connection. There are different types, which differ in the number of pins and thus the area of use.
A HIGO / Julet connector is generally quite firm because it is waterproof. It can be disconnected by pulling, NOT twisting. If twisted, the pins could be damaged.
Please note the arrows on the outside - they help to align and fit the connectors. When the connections are properly plugged together, no coloured plastic should be visible.
SHIMANO Right Shift Lever 7-speed
SL-M315-7R
SHIMANO - RAPIDFIRE PLUS - Right Shift Lever - Clamp Band - 7-speed
For reliable mountain bike shifting, SHIMANO's SL-M315 RAPIDFIRE shift lever is suited to quick shifting, giving riders the ability to downshift three gears in one stroke.
FEATURES
Light shifting operation, wider compatibility, and suitable for internal cable routing
Slim main lever body
RAPIDFIRE PLUS
Streamlined cockpit experience
Gear display positioned below the handlebar
Numbered gear display indicates gear position at a glance
OPTICAL GEAR DISPLAY
FEATURES
Light shifting operation, wider compatibility, and suitable for internal cable routing
Slim main lever body
RAPIDFIRE PLUS
Streamlined cockpit experience
Gear display positioned below the handlebar
Numbered gear display indicates gear position at a glance
OPTICAL GEAR DISPLAY
€11.99*
€20.95*(42.77% saved)
