Extra wide Front Hub for 100mm rims for Disc Brakes, 144 holes

€79.95*

Product number: VRN144
Product information "Extra wide Front Hub for 100mm rims for Disc Brakes, 144 holes"

Extra wide Front Hub with disc brake mount

  • for example 100 mm (~3,94 inches) rims and extra wide forks
  • 144 holes
  • 200 mm (~7.87 inches) axle
  • mounting size: 150 mm (~5,90 inches)
  • Pitch circle inside 65 mm (~2,56 inches)
  • Bolt circle diameter outside 75 mm (~2,95 inches)
  • spacing between flanges: 98 mm (~3,86 inches)
  • Weight: 840 gr. (~1,85 pounds)
  • Disc brake mounts
  • Suitable for spokes up to 2.3 mm / 0,09 inch in diameter.
