Controller box, electronics box with seal for E-Bike Uni Moke and Swing The controller box is made of robust plastic. In addition to attaching the controller to your e-bike, it also protects it. Dimensions: Outer dimension: ~ 21cm x 10.7cm x 3.4cm Inner dimensions: ~ 15.5 cm x 8.2 cm x 2.5 cm The box can be fitted to the frame of the Urban Dirvestyle Uni Moke and Swing bikes. It is screwed to the frame from below with the help of 4 screws. The cables are pulled upwards into the frame. The scope of delivery includes the controller box and the matching self-adhesive seal.

SHIMANO Right Shift Lever 7-speed SL-M315-7R SHIMANO - RAPIDFIRE PLUS - Right Shift Lever - Clamp Band - 7-speed For reliable mountain bike shifting, SHIMANO's SL-M315 RAPIDFIRE shift lever is suited to quick shifting, giving riders the ability to downshift three gears in one stroke.                 FEATURES Light shifting operation, wider compatibility, and suitable for internal cable routing Slim main lever body RAPIDFIRE PLUS Streamlined cockpit experience Gear display positioned below the handlebar Numbered gear display indicates gear position at a glance OPTICAL GEAR DISPLAY       FEATURES Light shifting operation, wider compatibility, and suitable for internal cable routing Slim main lever body RAPIDFIRE PLUS Streamlined cockpit experience Gear display positioned below the handlebar Numbered gear display indicates gear position at a glance OPTICAL GEAR DISPLAY

Wiring harness 1T4 Technical data: Transmission of power and data between e.g. the controller and the brake sensors, the thumb throttle and the display Waterproof plugs / connectors Cable length: ~ 56 cm / 22.05 inches, incl. connector ~ 66 cm / 26 inches Connections: 3x female 3-PIN Jullet connector yellow 1x female 5-PIN Jullet connector green 1x male 2-PIN Jullet connector red 1x male 9-PIN Jullet connector black General information: HIGO / Julet plugs are common on many e-bikes because they provide a firm and waterproof connection. There are different types, which differ in the number of pins and thus the area of use. A HIGO / Julet connector is generally quite firm because it is waterproof. It can be disconnected by pulling, NOT twisting. If twisted, the pins could be damaged. Please note the arrows on the outside - they help to align and fit the connectors. When the connections are properly plugged together, no coloured plastic should be visible.

RD-FT35-A-SS The Shimano Tourney FT35 7-speed rear derailleur has a short cage and is compatible with 6/7-speed systems. Ideal for older bikes or models with entry-level transmission systems, the Shimano Tourney FT35 7-speed rear derailleur offers reliable shifting performance in difficult terrain and riding conditions. FEATURES Less maintenance by suitable feature Double tension rear derailleur Wheel-type cable guide pulley for strong against cable bending Enough lower profile, Enough ground clearance to avoid rear derailleur to hit obstacles Upgraded appearance (RD-FT55) Interchangeable with SHIMANO MTB 7/6-speed system Front single use only Compatible with 11T top rear sprocket (total capacity 17T)

204 Kenda Krusade Extra Wide Tire 20 x 4  Diameter: 406 98 - 406 Ideal for the 20 inch fat e-bikes! This tire fits on all 20" Classic Cycle rims wider than 67 mm (~2,64 inches) ! But please check frame/fork for clearance! On a 82 mm (~3,22 inches) rim the tire is about 95 mm (~3,74 inches) wide and it will 79 mm (~3,11 inches) protrude over the rim. Diameter over all on this rim: 580 mm (22,83 inches) 60 TPI 5-30 PSI  /   0,4 -2.1 bar  /  40 - 210 KPA Weight: ~ 990 g (~ 2,18258 pounds) If you assemble the tire on wide rims not to put more pressure than 30 PSI. It could blast. This offer includes 1 piece only

Pre-assembled Bafang wiring harness 1T4 with 2PIN extension cable in cable protection hose. Technical data of Bafang wiring harness 1T4: Transmission of power and data between the controller and the brake sensors, thumb throttle and display. Compatible with Bafang hub motors Waterproof plugs / connectors Cable length: ~ 70 cm / 27,55 inches, incl. connector ~ 80 cm / 31,5 inches Connections: 1x male 3-PIN Julet connector yellow for throttle / thumb throttle. 1x male 5-PIN Jullet connector green for display 2x female 3-PIN Jullet connector yellow for shift / brake sensor 1x male 8-PIN Jullet connector black for controller Technical data of Extension cable for Ebike: Connector: 2-pin HIGO / Julet (1x male - 1x female) Water resistance: IP65 Cable length: 100 cm / 39,37 inches Plug connection: red Outer material: ABS plastic Technical data cable protection hose: Keeps cables tidy and protected! Diameter: ~ 20 mm Length: ~ 850 mm Fabric hose with practical Velcro fastener over the entire length General information: HIGO / Julet plugs are common on many e-bikes because they provide a firm and waterproof connection. There are different types, which differ in the number of pins and thus the area of use. A HIGO / Julet connector is generally quite firm because it is waterproof. It can be disconnected by pulling, NOT twisting. If twisted, the pins could be damaged. Please note the arrows on the outside - they help to align and fit the connectors. When the connections are properly plugged together, no coloured plastic should be visible.
