Original frame for UNI Micro by Urban Drivestyle Berlin, black matt
Build your own Micro Ebike with foldable elements!
Included in delivery is:
frame with fork
front light
crankset / crank set for 9/16 inch pedals
rear rack with transport wheels
pre-assembled cables and connectors
Only the frame with the parts described above is offered, not the entire bike!
The pictures of the complete bike are for information only.
******************************************************************************************************************************************
For information:
The bike, which is not offered here, was described by Urban Drivestyle as follows:
UNI MICRO - ELECTRIC FOLDING BIKE.
The UNI Micro is a highly affordable, smart electric folding bike packed with features!
SMALL, SMART AND ROBUST!
Our aim was to create a small, smart and robust electric folding bike that can be parked in the tightest of spaces and has all the benefits of a folding bike without sacrificing comfort, safety and looks!
Unique and simple folding mechanism
UNI Micro's specially designed folding mechanism lets you fold it in seconds in just three easy steps:Fold the handlebar, then the handlebar stem and slide the seat all the way down, DONE!
UNI Micro not only folds up in seconds, but can also be parked on end thanks to its built-in wheels on the luggage rack.
FEATURES
Electric Pedal Assist Cycle (EPAC)
Max. permitted speed: 25km/h (Germany / EU-wide)
Range: 50km
Brakes: High performance Bowden cable disc brakes
Material: Aircraft aluminium frame - TIG/WIG welded
Tyres: Extra thick 16 inch balloon tyres
Attached accessories: Integrated bottle cage, LED lights front & rear, rear rack with transport wheels, phone holder & USB port (no lock included - pictures may differ from actual delivery!)
ELECTRONIC COMPONENTS
Motor: MXUS 250W front hub motor
Battery: 7.6Ah 273.6Wh removable battery with Samsung cells
Light: integrated LED front & rear light
DIMENSIONS & WEIGHT
Saddle height: 94cm to 116cm
Frame: L 131cm x W 62cm x H 102cm
Max. Load capacity: Up to 110kg
Folding dimensions: 131cm x 26cm x 82cm
Adjusted for riders up to 190cm
Weight: 17kg
16 inch wheelset aluminium rim with 250W MXUS front wheel motor, 16 x 2.125Technical specifications front wheel with motor MXUS XF11F :
Position: Front wheel motorWheel diameter (inch): 16Construction: Geared motorRated voltage: 36VRated power: 250WMax torque: 32 NmColour: Black Weight: ~ 3.2 gOperating temperature: -20 - 45℃Volume: <50
Front wheel installation parameters:Brake: disc brake mount, 44 mm 6 hole disc brake 160 mm.Spokes: 2.34 mm blackMounting width: 110 mm16 inch - at tyre seat: 305 mm with bicycle diameter tyres: 57-305 = 16 x 2.125Cable connection: shaft, left sideCable length: ~ 10 mmConnection: 9 pin Jullet, male
Technical specifications rear wheel:
Position:Rear wheelWheel diameter (inch): 16Colour: blackSpokes: 2.34 mm blackFreewheel sprocket 14 teethRear wheel mounting pattern:Installation width: 135 mmRim diameter: 16 inch 305 Brake: Disc brake mount, 44 mm 6 hole, disc 160 mm
Tests & certification:
IP code: IP X5Certification: ROHS / CESalt Spray Test Standard(h): 96Special features:
incl. mounting material according to illustrationWeight front and rear wheel: ~ 5.25 kg
1/2" to 9/16" Pedal Thread Adaptors
Black, CRO MO
These adaptor bushings have a male 1/2"-20 thread to fit into your one-piece crank, and a standard 9/16"-20 female thread that will let you install standard 9/16" pedals, even modern clipless pedals.
These install with a 15 mm (~0,59 inches) pedal wrench.
Length over all: 32 mm (~1,26 inches)
Brings the pedal 21 mm (~0,83 inches) more out
Weight 54 gr. (~0,12 pounds)/pair
Perfect Quality
9/16 Zoll = 14.28 mm
11/20 Zoll = 14 mm
1/2 Zoll = 12.7 mm
Wheel Cover 20 inch black
black plastic
Diameter of the hole in the middle: 70 mm (~2,76 inches)
Overall diameter: 385 mm (~15,16 inches)
2 pieces for one 20 inch rim
€29.95*
