Aluminium Alloy Rim 20 inch., 82 mm (~3,23 inches) wide
ETRTO: 406
double wall 82
Wide:
82 mm (~3,23 inches)
inner size:
75 mm (~2,95 inches)
Holes:
36
colour:
black
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
1000 g (~2,20 pounds)
Aluminium Alloy Rim 20 inch., 82 mm (~3,23 inches) wide with cut out
ETRTO: 406
double wall 82
Wide:
82 mm (~3,23 inches)
inner size:
75 mm (~2,95 inches)
Holes:
36 (offset from the middle 15,5 mm)
colour:
black
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
882 g (~1,95 pounds)
Wheel Cover 20 inch black
black plastic
Diameter of the hole in the middle: 70 mm (~2,76 inches)
Overall diameter: 385 mm (~15,16 inches)
2 pieces for one 20 inch rim
Aluminium Alloy Rim 20 inch., 46 mm (~1,81 inches) wide black matte
ETRTO: 406
double wall 46
Wide:
46 mm (~1,82 inches)
inner size:
39 mm (~1,53 inches)
Holes:
36
colour:
black matte
Rim diameter for calculating the spoke length:
376 mm (~14,80 inches)
eight:
610 g (~1,34 pounds)
Aluminium Alloy Rim 20 inch., 102 mm (~4,01 inches) wide
ETRTO: 406
double wall 102
wide:
102 mm (~4,01 inches)
Inner size:
95 mm (~3,74 inches)
holes:
36
colour:
Black matte
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
1100 g (~2,42 pounds)
Aluminium Alloy Rim 20 inch., 102 mm (~4,01 inches) wide
ETRTO: 406
double wall 102
Wide:
102 mm (~4,01 inches)
inner size:
95 mm (~3,74 inches)
Holes:
36
colour:
high polished
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
1060 g (~2,34 pounds)
Aluminium Alloy Rim 20 inch., 82 mm wide
ETRTO: 406
double wall 82
wide:
82 mm (~3,23 inches)
Inner size:
75 mm (~2,95 inches)
holes:
32
colour:
black matte
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
1000 g (~2,20 pounds)
Aluminium Alloy Rim 20 inch., 102 mm wide
ETRTO: 406
double wall 102
wide:
102 mm (~4,01 inches)
Inner size:
95 mm (~3,74 inches)
holes:
32
colour:
black matte
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
1100 g (~2,43 pounds)
Offset / half distance:
~ 17,5 mm (~0,689 inches)
Aluminium Alloy Rim 20 inch., 67 mm (~2,64 inches) wide
ETRTO: 406
single wall 67
Wide:
67 mm (~2,64 inches)
inner size:
60 mm (~2,36 inches)
Holes:
36
colour:
black matte
Rim diameter for calculating the spoke length:
386 mm (~15,20 inches)
Weight:
660 g (~1,45 pounds)
Aluminium Alloy Rim 20 inch., 67 mm (~2,64 inches) wide, double wall
ETRTO: 406
double wall 132
The ultimate ultra fat custom chopper wheel.
wide:
67 mm (~2,64 inches)
Inner size:
60 mm (~2,36 inches)
holes:
36
colour:
high polished
Rim diameter for calculating the spoke length:
386 mm (~15,20 inches)
Weight:
~ 885 g (~1,95 pounds)
For all 20 inch Classic Cycle tires. But please check frame/fork for clearance!
Aluminium Alloy Rim 20 inch., 57 mm (~2,24 inches) wide black matte
ETRTO: 406
single wall 57
wide:
57 mm (~2,24 inches)
Inner size:
50 mm (~1,97 inches)
holes:
36
colour:
black matte
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
610 g (~1,34 pounds)
204 Front Wheel Magnesium 20 inch Fat Bike 84 mm black with Disk
20 inch Fat Bike front wheel
glossy black laquered magnesium rim,
new 4 Spoke Design
strudy, strong and sexy
disc brake mount 44 mm
over locknut dimension: 135 mm
4 spokes design
axle 9,5 mm diameter with bolt on
rim width: 84 mm
weight: ~ 1850 g
Aluminium Alloy Rim 20 inch., 102 mm (~4,01 inches) wide
ETRTO: 406
double wall 102
Wide:
102 mm (~4,01 inches)
inner size:
95 mm (~3,74 inches)
Holes:
36
colour:
raw
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
1075 g (~2,37 pounds)
Aluminium Alloy Rim 20 inch., 132 mm (~5,20 inches) wide
ETRTO: 406
single wall 132
the ultimate ultra fat custom chopper wheel
Wide:
132 mm (~5,20 inches)
inner size:
125 mm (~4,92 inches)
Holes:
36
colour:
black matte
Rim diameter for calculating the spoke length:
384 mm (~15,12 inches)
Weight:
1095 kg (~2,41 pounds)
Please check frame/fork for clearance!
Aluminium Alloy Rim 20 inch., 67 mm (~2,64 inches) wide
ETRTO: 406
single wall 67
Wide:
67 mm (~2,64 inches)
inner size:
60 mm (~2,36 inches)
Holes:
36
colour:
high polished
Rim diameter for calculating the spoke length:
386 mm (~15,20 inches)
Weight:
640 g (~1,41 pounds)
Aluminium Alloy Rim 20 inch., 67 mm (~2,64 inches) wide
ETRTO: 406
single wall 67
the ultimate ultra fat custom chopper wheel
Wide:
67 mm (~2,64 inches)
inner size:
60 mm (~2,36 inches)
Holes:
36
colour:
raw
Rim diameter for calculating the spoke length:
386 mm (~15,20 inches)
Weight:
645 g (~1,42 pounds)
Rear Wheel OPC 20 inch black silver with disk mount and free wheel
20 inch Bike rear wheel (406)
Alu glossy black and lathed silver rim,
new 18 Spoke Jet Engine Design
strudy, strong and sexy
disc brake mount 44 mm
over locknut dimension: ~ 115 mm (~ 4,52 inch)
18 spokes design
axle ~ 9,2 mm ( ~ 0,36 inch) diameter with bolt on, length: ~ 165 mm ( 6,89 inch)
rim width: outer: 34 mm (1,38 inch). Innerwidth: 25 mm (0,984 inch)
weight: ~ 1670 g (~3,68 lbs)
Aluminium Alloy Rim 20 inch., 132 mm wide
ETRTO: 406
single wall 132
wide:
132 mm (~5,20 inches)
Inner size:
125 mm (~4,91 inches)
holes:
32
colour:
black matte
Rim diameter for calculating the spoke length:
384 mm (~15,12 inches)
Weight:
1095 g (~2,41 pounds)
Offset / half distance:
~ 32 mm (~1,259 inches)
Please check frame/fork for clearance!
Rear Wheel OPC 20 inch black silver with disk mount and free wheel
20 inch Bike rear wheel (406)
Alu glossy black and lathed silver rim,
new 5 Spoke Hurricane Design
strudy, strong and sexy
disc brake mount 44 mm
over locknut dimension: ~ 115 mm (~ 4,52 inch)
5 spokes design
axle ~ 9,2 mm ( ~ 0,36 inch) diameter with bolt on, length: ~ 165 mm ( 6,89 inch)
rim width: outer: 34 mm (1,38 inch). Innerwidth: 25 mm (0,984 inch)
weight: ~ 1670 g (~3,68 lbs)
204 Bafang wheel set with 500W motor, die-cast aluminium, 20 x 4
Technical specifications rear wheel:
Position: rear wheel motor
Wheel diameter (inches): 20
Construction: Geared motor
Rated voltage: 48V
Rated power: 500W peak
Control power: 250W
Factory set for support up to 25 km/ - unchangeable
Max torque: 80 N.m
Power: ≥ 80
Colour: Black / Silver
Operating temperature: -20 - 45℃
Volume: <60
Installation parameters rear wheel:
Brake: disc brake mount, 44 mm 6 holes
Installation width: 180 mm
Max. Diameter rim: 422 mm
Cable connection: Shaft, right side
Cable length: ~ 200 mm
Connection: 9 Pin Jullet, male
Technical specifications front wheel:
Position: front wheel
Wheel diameter (inches): 20
Colour: Black / Silver
Installation parameters front wheel:
Installation width: 135 mm
Max. Diameter rim: 422 mm
Brake: Disc brake mount, 44 mm 6 hole
Tests & Certification:
IP Code: IP X5
Certification: ROHS / CE
Salt Spray Test Standard(h): 96
Special features:
Including installation material like pictured.
Weight: ~ 10 kg
Dimensions:
Dim A
100 mm
Dim B
76.6 mm
Dim C
422 mm
Dim D
44 mm
Dim E
33 mm
Dim F
2-M12X1.25-6g
Dim G
0
Dim H
26.5 mm
Dim I
15.25 mm
Dim OLD
175 mm
Dim WL
87.5 mm
Dim WR
87.5 mm
204 Front Wheel 20 x 4 inch Fat Bike 80 mm black with silver hub and disk mount, 2nd choice
20 x 4 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm
strudy, strong and sexy
alumnium silver Hub with disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
axle 9,5 mm diameter with bolt on
rim width: 80 mm
weight: ~ 1550 g
Hint:
According to the picture, the spoke holes in the rim base are a little unsightly - unheard of with obligatory use of a rim tape!
Surface shows oily traces due to production.
204 Front Wheel 20 inch Fat Bike 80 mm glossy black with disk mount
20 inch Fat Bike front wheel
glossy black matte anodized alu rim,
36 Spokes 2,6 mm stainless
strudy, strong and sexy
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
axle 9,5 mm diameter with bolt on
rim width: 80 mm
weight: ~ 1550 g
Aluminium Alloy Rim 20 inch., 82 mm (~3,23 inches) wide
ETRTO: 406
double wall 82
Wide:
82 mm (~3,23 inches)
inner size:
75 mm (~2,95 inches)
Holes:
36
colour:
high polished
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
1000 g (~2,20 pounds)
Rear Wheel OPC 20 inch black silver with disk mount and free wheel
20 inch Bike rear wheel (406)
Alu glossy black and lathed silver rim,
new I - Cross Design
strudy, strong and sexy
disc brake mount 44 mm
over locknut dimension: ~ 115 mm (~ 4,52 inch)
5 double spokes design
axle ~ 9,2 mm ( ~ 0,36 inch) diameter with bolt on, length: ~ 165 mm ( 6,89 inch)
rim width: outer: 34 mm (1,38 inch). Innerwidth: 25 mm (0,984 inch)
weight: ~ 1670 g (~3,68 lbs)
204 MXUS Front wheel complete with tyre and tube 20 x 4 - 80 mm wide
20 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm black
Hub: Quando
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
rim width: 80 mm
ready assembled
with rim tape and tube
with Innova allround tire 20 x 4
weight: ~ 3200 g
This Items was produced for Urban Drive Style UDX Model
204 Front Wheel MXUS Bafang 20 inch Fat Bike 80 mm black with disk mount
20 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm
strudy, strong and sexy
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
axle 9,5 mm diameter with bolt on
rim width: 80 mm
weight: ~ 1550 g
Aluminium Alloy Rim 20 inch., 82 mm (~3,23 inches) wide
ETRTO: 406
double wall 82
Wide:
82 mm (~3,23 inches)
inner size:
75 mm (~2,95 inches)
Holes:
36
colour:
raw
Rim diameter for calculating the spoke length:
383 mm (~15,08 inches)
Weight:
1000 g (~2,20 pounds)
Aluminium Alloy Rim 20 inch., 80 mm (~3,15 inches) wide
ETRTO: 406
Wide:
80 mm (~3,15 inches)
inner size:
74 mm (~2,91 inches)
Holes:
36
colour:
black
Rim diameter for calculating the spoke length:
387 mm (~15,23 inches)
Weight:
780 g (~1,72 pounds)
204 Front Wheel 20 x 4 inch Fat Bike 80 mm black with silver hub and disk mount
20 x 4 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm
strudy, strong and sexy
alumnium silver Hub with disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
axle 9,5 mm diameter with bolt on
rim width: 80 mm
weight: ~ 1550 g
204 Bafang wheel front die-cast aluminium, 20 x 4
Technical specifications front wheel:
Position: front wheel
Wheel diameter (inches): 20
Colour: Black / Silver
Installation parameters front wheel:
Installation width: 135 mm
Max. Diameter rim: 422 mm
Brake: Disc brake mount, 44 mm 6 hole
Special features:
Including installation material like pictured.
Weight: ~ 3,3 kg
Dimensions:
Dim A
100 mm
Dim B
76.6 mm
Dim C
422 mm
Dim D
44 mm
Dim E
33 mm
Dim F
2-M12X1.25-6g
Dim G
0
Dim H
26.5 mm
Dim I
15.25 mm
Dim OLD
175 mm
Dim WL
87.5 mm
Dim WR
87.5 mm
204 Front wheel complete with tire and tube 20 x 4 - 80 mm wide
20 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm black
Hub: Quando
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
rim width: 80 mm
ready assembled
with rim tape and tube
with Speedster 20 x 4 Vee Rubber
weight: ~ 3200 g
This Items was produced for Urban Drive Style UDX Model
204 Front wheel complete with tire and tube 20 x 4 - 80 mm wide
20 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm black
Hub: Quando
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
rim width: 80 mm
ready assembled
with rim tape and tube
with E-Speedster 20 x 4 Vee Rubber
weight: ~ 3200 g
This Items was produced for Urban Drive Style UDX Model
204 Front wheel complete with tire and tube 20 x 4 - 80 mm wide
20 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm black
Hub: Quando
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
rim width: 80 mm
ready assembled
with rim tape and tube
with E-Speedster 20 x 4 Vee Rubber
weight: ~ 3200 g
This Items was produced for Urban Drive Style UDX Model
204 Front wheel complete with tire and tube 20 x 4 - 80 mm wide
20 inch Fat Bike front wheel
black glossy powder coated alu rim,
36 Spokes 2,6 mm
Hub: black
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
rim width: 80 mm
ready assembled
with rim tape and tube
with Tire Speedster 20 x 4 Vee Tire
weight: ~ 3200 g
This Items was produced for Urban Drive Style UDX Model
204 Front wheel complete with tyre and tube 20 x 4 - 80 mm wide
20 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm
Hub: silver
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
rim width: 80 mm
ready assembled
with rim tape and tube
with Kenda Krusade tire
weight ~ 3200 g
This Items was produced for Urban Drive Style UDX Model
204 Front wheel complete with tire and tube 20 x 4 - 80 mm wide
20 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm black
Hub: Quando
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
rim width: 80 mm
ready assembled
with rim tape and tube
with Speedster Whitewall 20 x 4 Vee Rubber
weight: ~ 3200 g
This Items was produced for Urban Drive Style UDX Model
204 Front wheel complete with tire and tube 20 x 4 - 80 mm wide
20 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm black
Hub: Quando
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
rim width: 80 mm
ready assembled
with rim tape and tube
with Innova Semi Slick 20 x 4
weight: ~ 3200 g
This Items was produced for Urban Drive Style UDX Model
204 Front wheel complete with tire and tube 20 x 4 - 80 mm wide
20 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm black
Hub: silver
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
rim width: 80 mm
ready assembled
with rim tape and tube
with E-Mission Command Whitewall 20 x 4 Vee Rubber
weight: ~ 3200 g
This Items was produced for Urban Drive Style UDX Model
204 Front wheel complete with tire and tube 20 x 4 - 80 mm wide
20 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm black
Hub: silver
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
rim width: 80 mm
ready assembled
with rim tape and tube
with Mission Command Skinwall 20 x 4 Vee Rubber
weight: ~ 3200 g
This Items was produced for Urban Drive Style UDX Model
204 Front wheel complete with tire and tube 20 x 4 - 80 mm wide
20 inch Fat Bike front wheel
black matte anodized alu rim,
36 Spokes 2,6 mm black
Hub: silver
disc brake mount 44 mm 6 holes
over locknut dimension: 135 mm
rim width: 80 mm
ready assembled
with rim tape and tube
with E-Chicane 20 x 4 Vee Rubber
weight: ~ 3200 g
This Items was produced for Urban Drive Style UDX Model
€189.95*
This website uses cookies to ensure the best experience possible. More information...
